ZU4204BI-QH, PUMP ZU4 VE42Q 1STD230 4L HX Enerpac Pump
Specifications
| Power Source | Electric |
|---|---|
| Pump Series | ZU4 Series |
| Flow Group | ZU4 |
| Maximum Operating Pressure | 10,000 psi |
| Rated Oil Flow | 60 in³/min @ 10,000 psi |
| Motor Power | 1.7 hp |
| Voltage | 208-240V |
| Phase | Single Phase |
| Frequency | 50/60 Hz |
| Reservoir Capacity | 231 in³ |
| Valve Model | VE42Q |
| Valve Configuration | Single-solenoid torque wrench valve |
| Valve Operation | Solenoid |
| Valve Function | Advance / Retract |
| Pendant Control | Yes |
| LCD Control | No |
| Venturi Valve Technology | No |
| Usable Oil Capacity | 231 in³ |
| Oil Flow – Max Pressure | 60 in³/min @ 10,000 psi |
