ZE4420SB is an Enerpac ZE4 electric hydraulic pump with a VE43 solenoid valve and pendant control for double-acting cylinders. The induction-motor platform suits extended-duty manufacturing and workshop use.
Its larger oil supply and 60 in³/min flow at 10,000 psi are relevant when sizing a circuit for higher oil demand. The four-way, three-position tandem-center valve provides advance, hold and retract control.
Size the complete circuit
- Calculate usable oil demand from the cylinder arrangement and hose lengths.
- Confirm the 115 V, single-phase, 50/60 Hz electrical supply.
- Check whether the working-pressure flow meets the required cylinder speed.
- Verify mounting space and any required pump options.
Ask PLYET to review your cylinder configuration before ordering the pump.
Specifications
| Power Source | Electric |
|---|---|
| Pump Series | ZE Series |
| Flow Group | ZE4 |
| Maximum Operating Pressure | 10,000 psi |
| Rated Oil Flow | 60 in³/min @ 10,000 psi |
| Motor Power | 1.5 hp |
| Voltage | 115V |
| Phase | Single Phase |
| Frequency | 50/60 Hz |
| Reservoir Capacity | 1201.2 in³ |
| Valve Model | VE43 |
| Valve Configuration | 4-Way, 3-Position |
| Valve Operation | Solenoid |
| Valve Function | Advance / Hold / Retract |
| Cylinder Compatibility | Double-Acting |
| Pendant Control | Yes |
| LCD Control | Yes |
| Venturi Valve Technology | No |
